The Art of Colour and Coatings

5 min read29 May 2024

In modern architecture, function and form come together harmoniously to create structures that are both practical and visually appealing. Kingspan Insulated Panels offer a range of colours and coatings.

With an extensive portfolio of colours, finishes and coating options available across its insulated roof and wall panels, Kingspan provides architects and building owners with greater design flexibility while supporting the aesthetic and performance requirements of modern buildings.

The Evolution of Insulated Panels

Insulated panels, commonly found in large industrial buildings, were once considered purely functional, with a grey trapezoidal profile as the default design. However, with the continued evolution of design principles, these panels have become far more versatile. Modern Kingspan insulated panels are no longer the monotonous structures of the past. They have evolved into canvases that allow architects to unleash their creativity.

Colour Matters

Colour is ever-present, influencing our emotions, actions and reactions. It plays a vital role in how we perceive a structure. So why should a building, particularly a functional one such as a warehouse, be deprived of it? At Kingspan, we believe it should not.

Our insulated panels provide a dual benefit: reliable thermal and structural performance combined with a rich palette of colour options. These panels are suited to a variety of architectural styles, from bold angular details to smooth curves, and complement innovative daylighting solutions. Kingspan’s colour options allow you to create a façade that reflects the fiery hues of a sunset or the serene tones of the ocean. The possibilities are endless, ranging from vibrant solid colours and shimmering metallic finishes to subtle textured effects.

Kingspan Coating Variants

Kingspan Insulated Panels offer a wide range of coatings to meet different building requirements:

  • Kingspan Spectrum™ is a 50 μm polyurethane coating for surfaces requiring enhanced corrosion resistance, suitable for both external and internal applications. It is characterised by outstanding durability and resistance to weathering, corrosion and UV radiation. It provides excellent colour and gloss retention. In addition, its good flexibility makes it highly resistant to mechanical damage.

  • Kingspan Wood Décor is a polyester coating that combines the aesthetic appearance of natural timber with the durability and weather resistance required for external building applications. This polyester coating has a thickness of 25–38 μm. Its matt finish and UV resistance make it a popular choice.

  • Kingspan PES Coating, designated SP as standard and with a nominal thickness of 25 μm, is a polyester paint coating applied to hot-dip galvanised steel sheet. Ideal for standard external environments, it is a versatile all-round choice.

  • Kingspan PEI Coating is a 15 μm polyester paint coating intended for internal use. It is a classic choice, available in a range of subtle grey-white shades.

  • Kingspan FoodSafe Coating is tailored for the food and hygiene industries. This modified polyvinyl chloride film, classified as PVC (F), with a nominal thickness of 120 μm (150 μm on request), ensures safety and hygiene. Resistant to mould and easy to clean, it is approved for food contact, making it a trusted choice for sensitive environments.

All coatings are aligned with our sustainability policy. They are free from harmful phthalates and heavy metals, helping to ensure a safe and healthy environment.

At Kingspan Insulated Panels, we believe that building design is not limited to shape or size, but also extends to an artful combination of colour, texture and finish. It is an expression of innovative design and practicality working together to make every building, no matter how functional, a masterpiece.
