Insulated roof panels
KS RW QuadCore® Roof Panel
- Insulated roof panels
The KS RW QuadCore® Roof Panel is a sandwich panel system with a trapezoidal pattern. Its use is recommended in case of a roof slope of at least 4°(7%). Minimum 10% (6°) is recommended for slopes covered with more than one panel or rooflight element, connected to lengthwise. The product is manufactured to meet relevant requirements for thermal insulation, fire performance, and service life.
- QuadCore® Technology insulation core
- Thermal transmittance for a 160 mm panel: U-value = 0.120 W/m²·K
- Reaction to fire: B-s2, d0 according to EN 13501-1:2018
Technical Information
KS RW QuadCore® Roof Panel has been tested and approved to comply with EN 14509:2013.
| Core Thickness [mm] | Airborne Sound Insulation Rw(C;Ctr) |
|---|---|
| 60 | NPD |
| 80 | NPD |
| 100 | NPD |
| 120 | NPD |
| 160 | NPD |
Documents & Downloads
All technical documents, BIM models and certificates in one place
